SINGLE DOOR
FINISH
You have nished installing your single door.
PARTS REQUIRED:
Center door in wall panel opening.
Hold door in position and keep level.
4
Screw hinge boards into wall supports and oor using (5) 3" screws as shown.
.
3
3" (7,6 cm)
Screws into the wall
Measure Gap between door trim and wall panel as shown.
Hold door in position and keep level.
Hinge-board must overhang wall panel at measurement shown .
Bottom of door trim is even with wall panel as shown.
Screw
3/8"
(1,0 cm)
3/8"
(1,0 cm)
Door trim even
with panel.
Door
Frame
Flush
Carefully cut bottom wall frame 2 x 4 ush with door frame
using a saw .
Be careful not to cut into oor panel!
5/8"
(1,6 cm)
5/8"
(1,6 cm)
5/8"
(1,6 cm)
5/8"
(1,6 cm)
1
UNIVERSAL DOOR
