YARDMAX YB5765 User Manual

No. Description QTY.
1 Spiral Assembly R 1
2 Washer 2
3 Big Washer 2
4 Sealing B20x35x7 3
5 Bolt M6x20 10
6 Spring Washer 6 11
7 Flat Washer 6 9
8 Oil Cup M10x1 1
9 Screw M5x10 1
10 Auger Gearcase Housing R 1
11 Shaft Sleeve 2
12 Worm Wheel 1
13 Key 5x7.5x19 1
14 Shear Pin 2
15 Shaft 1
16 Clip 1.8 9
17 Auger Gearcase Housing L 1
18 Spiral Assembly F 1
19 %HDULQJb56 1
20 Impeller Shaft 1
21 Roll Pin 6x37 2
22 Locknut M8 17
23 Shave Plate 1
24 Bolt M8x16 5
25 Worm Sleeve 1
26 %HDULQJb56 1
27 Bearing 51104 1
28 Washer 1
29 Impeller Assembly 1
30 Skid Shoe 2
31 Flange Locknut M8 4
32 %ROWb0x16 6
33 %HDULQJb567 4
34 Screw ST5.5x13 2
35 Bearing Housing 4
36 Bolt M8x20 6
37 Bolt M8x25 2
38 Plug 5
No. Description QTY.
39 Auger Housing Assy 1
40 Clean-Out Tool Mounting Bracket 1
41 Chute Clean-Out Tool 1
42 Discharge Chute 1
43 Bolt M8x35 1
44 Chute Linkage Plate 1
45 Lock washer 2
46 Handle Knob Assembly 1
47 Bolt M6x30 6
48 Discharge Chute Washer 1
49 Screw M5x6 2
50
Chute Flange Keeper 3
51 Flange Lock Nut M6 11
52 Bearing 6203-2RS 1
53 Bearing Housing 1
54 Big Pulley 1
55 Big Flat Washer 8 2
56 Spring Washer 8 2
57 Bolt M8x20 2
58 Flange Locknut M6x1.5 1
59 Locating Shaft 1
60 Driven Pulley Bracket 1
61 Bearing 6006-2RS 1
62 Driven Pulley Shaft 1
63 Driven Pulley 1
64 Chute Breaking Spring 2
65 Chute Breaking Plate 1
66 Washer 12 2
67 Locknut M10 1
68 Big Washer 8 4
69 Chute Tension Pulley Assy 1
70 Bearing Spacer 1
71 Tension Pulley Plate 1
72 Bolt M8x40 1
73 Plastic Sleeve 2
74 Oscillating Bar 1
75 Oscillating Plate 1
76 Belt Cover 1
PARTS LIST
28
Two-Stage Snow Blower
»
Operator’s Manual
Parts List
|
