No. Description QTY.
77 Screw M6x16 8
78 Drive Clutch Idler 1
79 Bolt M8x30 1
80 Bushing 1
81 Drive Clutch Idler Bracket 1
82 Spacer 1
83 Bolt M8x40 1
84 Engine 1
85 Spring Washer 10 1
86 Engine Washer 1
87 V-Belt 4LxA675 1
88 Belt Pulley 1
89 V-Belt M28 1
90 Key 6x6x45 1
91 Belt Blocker 1
92 &LUFOLSb 3
93 Bearing 6202-2RSN with Sealing 2
94 Split Washer 15 2
95 Shift Arm 1
96 Lock Screw M6x12 6
97 Friction Wheel Side Plate 2
98 Friction Wheel 1
99 Friction Wheel Shaft 1
100 Shaft Sleeve 1
101 Circlip 15 1
102 Bolt 8.8 M10x40 2
103 Washer 10 2
104 Locknut M6 6
105 Auger Cable Holder 2 1
106 Screw M8x16 14
107 Cable Roller 1
108 Roller Bushing 3
109 FT Bolt M6x25 2
110 Lock Pin 8 2
111 Wheel 2
112 Big Gear 1
113 Wheel Shaft 1
114 Big Washer 8 6
No. Description QTY.
115 Bolt M10x20 2
116 Bolt M8x35 4
117 Gearbox Housing 1
118 Bracket 1
119 Bolt M8x55 1
120 Spring 1
121 Frame Cover 1
122 Bolt M6x35 2
123 Nut M6 5
124 Washer 10 6
125 Supporting Plate 1
126
Bushing
1
127 Big Washer 6 6
128 Directional Chute Control Lever 1
129 Directional Chute Control Knob 1
130 Circlip 10 1
131 Locknut M6 1
132 Shifting Fork 1
133 Spring Clip 1
134 Bolt M6x30 1
135 Rubber Bushing 1
136 Arc Washer 8 1
137 Lever Bracket 1
138 Gear Shift Lever 1
139 Knob 1
140 Left Handle Pipe 1
141 Drive Clutch Cable 1
142 Gear Shift Board 1
143 Bolt M6x40 3
144 Chute Adjustable Cable 1
145 Screw M6x60 2
146 Bolt M10x55 2
147 Lever 1
148 Handle 2
149 Flange Lock Nut M10 2
150 Right Handle Pipe 1
151 Lever Bracket 2
152 Bolt Sleeve 2
153 Chute Crank Flange 1
29
|
Parts List
To Next Page
