YARDMAX YD8203 User Manual

PARTS LIST
No. Description Qty
37 Tensioner Pulley Bracket 1
38 Engine 1
39 Key 4.7×33 1
40 Belt Protect Frame 1
41 Bolt 5/16-24×30 2
42 Fixed Bracket 1
43 Washer 8 2
44 Bolt M10×60 2
45 Belt Pulley 1
46 Screw M5×12 1
47 Tensioner Pulley 1
48 Circlip 15 2
49 Bearing 6202-2Z 2
50 Circlip 35 1
51 Gear Box 1
52 Large Belt Pulley Cover 1
53 Nut M6 8
54 Bolt M6×20 1
55 Wheel Axle Press Board 2
56 Support Plate (right) 1
57 Belt Plate 1
58 Connecting Angle Block 1
59 Screw M6×25 2
60 Bolt M8×40 4
61 Bolt M10×65 w/glue 8
62 Nut M8 8
63 Cable Fixing Base 1
64 Rubber Mat 2
65 Support Plate (left) 1
66 Long Extension Spring 1
67 Skeleton Oil Seal 4
68
Weight Supporting Wheel
Weldment
4
69 Bearing 6204-2RS 8
70 Washer 10 6
71 Bolt M10×25 6
72 Axle Head Cover(47) 4
No. Description Qty
73 Track 180×60 2
74 Axle Head Cover(42) 2
75 Circlip 42 8
76 Bear 61905-2RS 4
77 Guiding Wheel 2
78 Sealing Ring30×42×7 2
79 Nut M16 2
80 Bolt M16x110 2
81 Underframe Weldment 1
82 Guide Wheel Axle 1
83 Bolt M10×20 4
84 Support Bracket 1
85 Flat Gasket 16 2
86 Plain Shaft 1
87 Pin 4×35 2
88 Dumper Box 1
89 Operation Lever Frame 1
90 Handle Frame Weldment 1
91 Nut M12 1
92 Washer 12 2
93 Extension Spring 1
94 Handle Sleeve 1
95 Guiding Spring 2
96 Locating sleeve 2
97 Gas Spring 1
98 Bolt M8×35 2
99 Pin 5×30 1
100 Gearshift Lever 1
101 Pin 3×30 1
102 Bolt M6×8 w/glue 1
103 Orientation Nut 1
104 Washer Groupware D20 1
105 O-Ring 11.2×1.8 1
106 Lever Mount Bracket 1
107 Seal FB17×40×7 2
108 Spline Shaft I 1
109 Duplex Slip Gear 1
No. Description Qty
1 Tensioner Pulley Cable 1
2 Safety Control Handle 1
3 Screw M6×16 1
4 Screw M5×20 2
5 Nut M5 2
6 Handle Sleeve 2
7 Throttle Cable 1
8 Throttle Lever 1
9 Hoop 1
10 ON/OFF Switch 1
11 Handle Frame Assembly 1
12 Lower Handle 2
13 Washer ø6 10
14 Screw M6×35 1
15 Screw M6×60 1
16
Right/Left Steering Lever
Cable
2
17 Screw M10×20 8
18 Washer10 26
19 Washer10 22
20 Bolt M8×16 6
21 Washer 8 43
22 Soleplate (left) 1
23 Bolt M8×25 11
24 Washer8 7
25 Handle Mounting Frame 1
26 Bolt M8×20 1
27 Soleplate (right) 1
28 Belt B32 1
29 Pulley Cover Weldment 1
30 Lever Knob 1
31 Lock Nut M10 11
32 Bolt 5/16-24×20 1
33 Bolt M10×70 1
34 Brake Cable 1
35 Driving Wheel 2
36 Nut M8 25
24
Mini Tracked Dumper
»
Operator’s Manual
YD8203PM01 - 1703
Parts List
|
09710US25M101.indd 24 2017/4/1 16:23:02
