Your YARDMAX tracked dumper comes partially assembled and contains the following:
CONTENTS SUPPLIED
1. Main Machine
2. Handlebar Assembly
3. Tipping Handle
4. Panel (Front)
5. Extendable Panel (Left Side)
6. Extendable Panel (Right Side)
7. Engine Guard
8. Panel (Bottom)
9. Gas Spring
10. Operator’s Manual & Engine Manual
11. Tools for Spark Plug Assembly
TOUCH-UP PAINT
Orange × 1
5
Light Gray × 1
12. Hardware Kit, Including
M10 × 20 × 4
1
M8 × 25 × 2
ø M16 × 238 × 1
2
× 2
M8 × 35 × 2
3
M8 × 30 × 2
M8 × 35 × 2
4
8
Mini Tracked Dumper
»
Operator’s Manual
YD8203PM01 - 1703
Contents Supplied
|
HARDWARE KIT
10
12
11
2
7
3
8
4
5
6
1
9
