YARDMAX YM0146 User Manual

No. Description QTY.
1 Cross Headed Screw M12x25 4
2 Nut M12 4
3 Mixing Blade 2
4 Flat Washer 10 2
5 Lock Washer 10 1
6 Nut M10 1
7 Drum 1
8 Cotter Pin
Ø
6×50 4
9 Flat Washer 4
10 Wheel 2
11 Front Frame 1
12 Swivel Bracket 1
13 Pivot Pin
Ø
12×240 1
14 Drum Support Frame 1
15 Flat Washer 6 5
16 Lock Washer 6 5
No. Description QTY.
17 Nut M6 5
18 Motor and Gear Box 1
19 R-Pin
Ø
3.5 2
20 Bolt M10x60 1
21 Pin 3x10 1
22 Pin Shaft 1
23 Spring 1
24 Pin Bushing 1
25 Cam Lever 1
26 Bolt M10x25 1
27 Rear Leg 1
28
Ø
3 R-Pin 1
29 Drum Handle 2
30
Ø
25 Handle Grip 2
31 Tube Plug 2
PARTS LIST
Parts List
|
14
Electric Concrete Mixer
»
Operator’s Manual
74109US25M101.indd 14 2017/7/4 17:22:39
