YARDMAX YM0146 User Manual

Your YARDMAX concrete mixer comes partially assembled and contains the following:
CONTENTS SUPPLIED
TOUCH-UP PAINT
Orange X 1
6
Light Gray X 1
Ø6 × 50 × 4
1
× 4
M10 × 60 × 1
Ø 3 × 1
2
M10 × 25 × 1
3
M12 × 25 × 4
4
Ø 3.5 × 2
5
1
2
7 8 9
3 4
5 6
HARDWARE KIT
11
10
1. Pivot Pin
2. Swivel Bracket
3. Drum Support Frame with motor
4. Drum
5. Drum Handles ( 1 pair)
6. Mixing Blades (1 Pair)
7. Wheels (1 Pair)
8. Rear Support Leg
9. Front Support Leg
10. Operator’s Manual
11. Hardware Bag:
6
Electric Concrete Mixer
»
Operator’s Manual
Contents Supplied
|
