model no. 054-5745-0 | contact us: 1.866.523.5218
34
Maintenance
CHAIN MAINTENANCE (See Fig. 31)
Use only a low-kickback chain on this saw. This fast-cutting chain provides kickback reduction when
properly maintained. For smooth and fast cutting, maintain the chain properly. The chain requires
sharpening when the wood chips are small and powdery, the chain must be forced through the wood
during cutting, or the chain cuts to one side. During maintenance of the chain, consider the following:
• Improper filing angle of the side plate can increase the risk of severe kickback.
• Raker (depth gauge) clearance.
• Too low increases the potential for kickback.
• Not low enough decreases cutting ability.
• If the cutter teeth hit hard objects such as nails and stones, or are abraded by mud or sand on
the wood, have an authorized service centre sharpen the chain.
NOTE: Inspect the drive sprocket for wear or damage when replacing the chain. If signs of wear or
damage are present in the areas indicated, have the drive sprocket replaced by an authorized service
centre.
NOTE: If you do not fully understand the correct procedure for sharpening the chain after reading the
instructions that follow, have the saw chain sharpened by an authorized service centre or replace with
a recommended low-kickback chain.
1/32 in. (0.6 mm)
Raker (Depth Gauge) Clearance
Fig. 31
Raker (depth gauge) clearance
1/32” (0.6 mm)
