ASSEMBLY
model no. 060-1314-4 | contact us: 1.866.523.5218
14
ASSEMBLY
UNPACKING
1. Set the shipping carton on a solid, flat surface.
2. Remove everything loose from the carton.
3. Cut down the bottom carton to allow a flat surface area to install the assembly parts
without scratching parts or cutting tires.
4. Now you are ready for assembly.
TOOLS REQUIRED
Part Size
Wrench (included) 13,16
ADDITIONAL PARTS
Part Part Qty. Usage
Shear Pins 4 Spare part (preassembled)
Clip (for auger) 4 Spare part (preassembled)
Starter Electric Cord 1 Accessory
Engine Oil 1
ASSEMBLY PARTS
Part
Part
Qty.
Description
Hardware
Qty.
Hardware
Reference
Tool(s) Needed
Discharge
Chute
1
M10 Hexagon
Lock Nut
1
16 mm wrench
Large Washer 1
N/A
Support Rod 1 N/A
Lower
Handle
1
M8 × 16 Self-tapping
Bolt
4
13 mm wrench
Cord Clamp
(preassembled)
1
N/A
Upper
Handle
1
M8 × 50 Half
Round Bolt
4
N/A
Curved Washer 4
N/A
Rotating Knob 4
N/A
Cable Tie 3
N/A
