FIG. A PARTS LIST SNOWBLOWER
Item Part Number Description Qty.
1 Figure E Auger Assembly 1
2 30133020025000 Flange Triangle Self-tapping Screw, M10 × 18, White Zinc 4
3 23012000105000A Quick Clip, T=1 mm, Black 2
4 2301300006A Wheel Shaft Washer, T=2, 16.2 × 36, Black 2
5 31013020015000 Thin Flat Key, B4 × 6 × 32, 45#, Black 2
6 2301600009A Wheel Assembly, 15 × 5, Airless, Rubber 2
7 Figure D Drivetrain Assembly 1
8 23041000530301A Belt Protection Cover, Black 1
9 23033000485000A Flange Triangle Self-tapping Screw, M6 × 16, White Zinc 2
10 23016000135000A Auger Belt Gates 5LXA935E (L × W × H = 935 × 16.6 × 8.2) 1
11 2303600007A
Drive Belt Megadyne HTD 840-5M15
(L × W = 840 × 15 / Pitch = 5 mm)
1
12 30133020035000 Flange Triangle Self-tapping Bolt, M8 × 16, White Zinc 8
13 Figure F Chute Assembly 1
14 2309900012 Cable Tie, 2.5 × 200 3
15 23062000780265A Lower Handle, Black 1
16 30913090085000 Half-Round Head Square Neck Bolt, M8 × 50, Blue White Zinc 4
17 21061000110301A Curved Washer 4
18 21061000400301A Rotating Knob, Black 4
19 23061000490301A Cord Clamp, Black 1
20 Figure G Handle Assembly 1
21 23089000025000A Power Outlet Wire 1
22 23089000035000A AC Start Line, 1830 mm 1
23 30323060035000 Flange Locking Nut, M8, Hexagon, Blue White Zinc 4
24 Figure B Engine Assembly 1
To Next Page
