Table of Contents

Know Your Mower

SPECIFICATIONS 2

KNOW YOUR MOWER 3

EXPLODED VIEW 4

PARTS LIST 5

ASSEMBLY 6

ATTACHING THE HANDLE 8

CUTTING HEIGHT ADJUSTMENTS 9

OPERATION 9

CHECKING THE ADJUSTMENT 10

SAFETY AND MAINTANCE 11

WARRANTY 12

Cutting path: 18" (45.7 cm)

Height adjustments: 1-3 1/8" (25-79 mm)

Weight: 26 Ib 7 oz (12 kg)

1.Top handle

2.Centre handle

pieces

3. Lower handle

4. Foam grip

5. Carriage bolts

6. Knobs

7. Reel mower

KNOW YOUR REEL MOWER

Before attempting to assemble, empty carton and compare parts with parts list above.

• Carefully remove the parts from the box.

• Inspect the parts to make sure no breakage or damage occured during shipping.

• Do not discard the packing material until all parts are examined.

• If any parts are damaged or missing, please call 1-866-523-5218 for assistance.

• Be sure to tighten the knobs when assembled to prevent the handle from rocking.

Yardworks 060-1526-0 User Manual
