Assembly Operation
ATTACHING THE HANDLE TO THE MOWER BASE
Align holes (1) at the lower end of each handle arm with posts (2) extending
from the mower base side plates. Mount the holes onto the posts, one at a
time, and press inward on handle to secure the fitting.
CUTTING HEIGHT ADJUSTMENTS
The cutting height of the mower adjusts from 25mm – 80mm with 5 positions for
adjustment height by moving the height adjustment levers to the required position.
To achieve the lowest cutting position, one at a time, move the adjustment levers
on both sides, located next to the smaller wheels, up to the highest position.
To achieve the highest cutting position, move the adjustment levers on both sides
to their lowest position.
Other cutting heights are achieved by moving the adjustment levers to any stop
between the highest and lowest positions.
•
•
•
•
2
1
The highest cutting position
The lowest cutting position
The height adjustment knob
