ASSEMBLING THE GUARD (See Fig. 1)
To avoid injury, always remove the battery pack before installing the guard, changing a
cutting line, or making any adjustments. If the guard is damaged, do not use the grass
trimmer/edger until it is replaced.
• Remove the battery pack.
• Invert the grass trimmer/edger to access the trimmer head.
• Using a cross-head screwdriver, remove the pre-installed screw (1) from the trimmer
head.
• Place the guard (2) on to the trimmer head and turn the guard 45° following the track on
the head.
• Align the screw hole on the guard with the screw hole on the trimmer head.
• Insert the screw into the trimmer head, fastening the guard in place.
Fig. 1
1
2
Assembly
!
WARNING: Replace the battery pack or charger
immediately if the battery case or charger cord is
damaged.
• Always make sure the string trimmer switch is OFF
before inserting or removing the battery pack.
• Always make sure the battery pack is removed and
the switch turned OFF, before inspecting, adjusting, or
maintaining any other part of the hedge trimmer.
• Read, understand, and follow the battery charger
instructions.
