ASSEMBLING THE LAWN MOWER
Loose Parts in Carton
Assembling the Handle
Grass catcher
Owner's Manu
al
1. Remove any packing material that may have been inserted between the upper and lower handles for
shipping purposes.
2. Align the holes (4) on the upper handle (1) with those on the middle handle (2). Insert the bolts (5),
and tighten them using the knobs (6) provided.
3. Align the holes (7) on the middle handles (2) and the lower handles (3).Insert the bolts (8), and tighten
them using the knobs (9) provided.
WARNING: Do not operate the mower without a proper trail shield, mulching plug, side discharge deflector,
motor/blade control, or other safety devices in place and in working order. Do not operate the mower wit
h
damaged safety devices. Doing so can result in injur
y
.
