Page #28 background image
model no. 060-1980-6 | contact us: 1.866.523.5218
28
Parts List
Item Description
QTY.
1 B type-Self tapping screw ST3.9x16 46
2 Battery pack 1
3 Right decorative cover 1
4 Right case 1
5 Bafe III 1
6 B type-Self tapping screw ST3.5x25 4
7 Battery pack bracket 1
8 Battery cover 1
9 Cylindrical pin 6x15 1
10 Filter 1
11 B type-Self tapping screw ST3.5x10 16
12 magnetic steel 1
13 Fixed bafe 1
14 Left case 1
15 left decorative cover 1
16 Motor base 1
17 Battery pack pop-up torsion spring 1
18 Control panel 1
19 The front cover 1
20 Platen I 3
21 Clip 2
22 Grass Broken straw 1
23 MOTOR PARTS 1
24 Wheel cover II 4
25 Retaining ring 4
26 Wheel cover I 4
27 Wheel hub 4
28 Lock knob II 2
29 B-large washer 6-C 4
30 Fixed block 2
31 Fixing nut 2
32 Base 1
33 Safety guard 1
34 Torsion spring 1
35 Grassed pressed skin 1
36 Press plate 2
37 B-open type blind rivet 4x13 4
38 Torsion spring 1
Item
Description
QTY.
39 Bafe 1
40 Support plate I 1
41 B-screw assembly M4x25 4
42 Bushing 1
43 Support plate II 1
44 Gasket 1
45 Blade 1
46 fasten function screw nut 1
47 Front axle assembly 1
48
B-type non-metallic insert
hexagonal locking thin nut M6
2
49 Linkage 1
50 Rear axle Roller Shaft 1
51 Press plate II 3
52 Right handle cover 1
53 Left handle cover 1
54 Grass box bracket 1
55 Grass box component 1
56 down Pushing Rod Assembly 1
57 Lock knob I 2
58 Power cord 1
59 Fixing bolts 2
60 Bar Pressure mount 1
61 Fixing support 1
62 Pressure bar xed cover 1
63 left switch cover 1
64 up Pushing Rod Assembly 1
65 Trigger torsion spring 1
66 Swtich Pickpocket 1
67 Button compression spring 1
68 Switch button 1
69 Signal switch 1
70 Right switch cover 1
71 Pressure bar 1
72 Terminal block (wiring cap) 2
73 B-small washer 8-A 2
74 Pusher plate 2
75 Push rod plug 2
