Model number 060-1980-6 | contact us: 1.866.523.5218
17” (43 CM) 2-IN-1 LAWN MOWER
1
Quick Start Guide
* This information is provided for your convenience. It does not replace the
instruction manual and safety instructions. The manual and safety instructions need
to be read and understood in their entirety.
ASSEMBLY
1. ASSEMBLING THE LOWER HANDLE
1) Insert the lower handle, washer, lower locking knob into the screw hole on the deck (See
Fig. A1).
2) Turn the locking knob clockwise and tighten it (See Fig. A2).
3) Repeat for the other side.
4) Check that the handles are FULLY secured.
2. ASSEMBLING THE UPPER HANDLE.
1) Insert the screw with circle washer into the hole of lower handle, hole of the upper
handle, square washer, locking knob (See Fig. B1).
2) Tighten the handle knob clockwise (See Fig. B2).
3) Repeat for the other side.
4) Check that the handles are FULLY secured.
A2
A1
B2
B1
