YASKAWA CDBR Series User Manual

3 WIRING
29
Fig. 11 Braking Resistor Unit Model LKEB-20P7 SPEC: B (Front Cover
Removed)
Note: 1. External terminals for SPEC: B models LKEB-
20P7 and 40P7 are located up to 20 mm further
inside the unit when compared to the same models
for SPEC: A.
2. External terminals for SPEC:B models LKEB-
21P5 to 27P5 and LKEB-41P5 to 47P5 are located
up to 15 mm higher on the unit when compared to
the same models for SPEC: A.
Thermal Overload Relay
(Automatically Reset)
Top S i de
Bottom Side
Control Circuit Terminals
B㧘P㧘1㧘2
Lead Wire Outlet
(Rubber Bush)
