(2) Braking Resistor Unit
Inverter
Resistor Spec.
(per unit)
Model Code No.
Voltage HP(kW)
200 to
230V
1 (0.75) 70W 200Ω
LKEB-20P7 72600-K2P70B
2 (1.5) 260W 100Ω
LKEB-21P5 72600-K2010B
3 (2.2) 260W 70Ω
LKEB-22P2 72600-K2020B
5 (3.7) 390W 40Ω
LKEB-23P7 72600-K2030B
7.5 (5.5) 520W 30Ω
LKEB-25P5 72600-K2050B
10 (7.5) 780W 20Ω
LKEB-27P5 72600-K2070B
15 (11) 2400W 13.6Ω
LKEB-2011 72600-K2110
20 (15) 3000W 10Ω
LKEB-2015 72600-K2150
25 (18.5) 4800W 8Ω
LKEB-2018 72600-K2180
30 (22) 4800W 6.8Ω
LKEB-2022 72600-K2220
380 to
460V
1 (0.75) 70W 750Ω
LKEB-40P7 72600-K4P70B
2 (1.5) 260W 400Ω
LKEB-41P5 72600-K4010B
3 (2.2) 260W 250Ω
LKEB-42P2 72600-K4020B
5 (3.7) 390W 150Ω
LKEB-43P7 72600-K4030B
7.5 (5.5) 520W 100Ω
LKEB-45P5 72600-K4050B
10 (7.5) 780W 75Ω
LKEB-47P5 72600-K4070B
15 (11) 1040W 50Ω
LKEB-4011 72600-K4110B
20 (15) 1560W 40Ω
LKEB-4015 72600-K4150B
25 (18.5) 4800W 32Ω
LKEB-4018 72600-K4180
30 (22) 4800W 27.2Ω
LKEB-4022 72600-K4220
40 (30) 6000W 20Ω
LKEB-4030 72600-K4300
50 (37) 9600W 16Ω
LKEB-4037 72600-K4370
60 (45) 9600W 13.6Ω
LKEB-4045 72600-K4450
