Introduction
This manual explains the specifications and handling of the Yaskawa LONWORKS Option for the Yaskawa models E7, P7, F7 and G7 drives. The
L
ONWORKS Option connects the drive to a LONWORKS network and facilitates the exchange of data utilizing the LonTalk
protocol. In this
document, the word “inverter”, “ac drive” and “drive” may be used interchangeably.
To ensure proper operation of this product, read and understand this manual. For details on installation and operation of the E7, P7, F7 and G7
drives, refer to the appropriate drive’s user and/or technical manual. All drive manuals and support files can be found on the CD that came with
the drive. They are also available for download at www.drives.com.
For information on L
ONWORKS contact the Echelon at www.echelon.com.
L
ONWORKS
Option Installation Guide document reference IG.AFD.20
E7 User Manual document reference TM.E7.01
E7 Programming Manual document reference TM.E7.02
E7B Drive/Bypass technical Manual document reference TM.E7B.01
F7 User Manual document reference TM.F7.01
F7 Programming Manual document reference TM.F7.02
F7 Parameter Access Technical Manual document reference TM.F7.11
P7 User Manual document reference TM.P7.01
P7 Programming Manual document reference TM.P7.02
G7 Technical Manual document reference TM.G7.01
GPD is a trademark of Yaskawa, Inc.
MODBUS
is a registered trademark of Schneider Automation, Inc.
L
ONWORKS
, Lon
, LonBuilder
, LonTalk
and LonManager
are registered trademarks of Echelon Corporation.
LonMaker, LonMark, LonLink and NodeBuilder are trademarks of Echelon Corporation.
All other trademarks are the property of their respective companies or organizations.
Note: Installing the L
ONWORKS Option on an F7 or G7 drive obstructs the 3CN and 4CN connectors. This means that I/O and encoder
feedback options cannot be installed concurrently with the L
ONWORKS Option on an F7 or G7 drive.
When used on a F7, G7 or P7 drive, the drive will appear as an E7 on the network.
