MP Series SIO (Extension) Driver
GP-Pro EX Device/PLC Connection Manual
15
6 Supported Device
Range of supported device address is shown in the table below. Please note that the actually supported range of
the devices varies depending on the External Device to be used. Please check the actual range in the manual of
your connecting equipment.
This address can be specified as system data area.
Device Bit Address Word Address
32
bits
Notes
System registers SB000000 - SB08191F SW00000 - SW08191
Input registers IB00000 - IBFFFFF IW0000 - IWFFFF
*1
*1 As for Input and Output registers, device 0x9000-0xFFFF cannot be written.
Output registers OB00000 - OBFFFFF OW0000 - OWFFFF
*1
Data registers MB000000 - MB65534F MW00000 - MW65534
• Please refer to the GP-Pro EX Reference Manual for system data area.
Cf. GP-Pro EXReference Manual "Appendix 1.4 LS Area (only for direct access
method)"
• Please refer to the precautions on manual notation for icons in the table.
)"Manual Symbols and Terminology"
