80
Carrier Frequency Varies According to Inverter Capacity (kVA).
(3) Carrier frequency can be automatically reduced to 2.5 kHz when (n75) is set
to 1 and the following conditions are satisfied.
Output frequency <
5Hz
Output frequency >
100%
Factory Setting (n75) is 0 (disabled)
Voltage Class
Capacity
hp(kW)
Initial Setting Maximum
Continuous
Output Current
(A)
Reduced
Current (A)
*1
Setting
Carrier
Frequency
200V
Single-phase
3-phase
0.13 (0.1) 4 10kHz 0.8
–
0.25 (0.2) 4 10kHz 1.6
0.5 (0.4) 4 10kHz 3.0
1 (0.75) 4 10kHz 5.0
2 (1.5) 3 7.5kHz 8.0 7.0
3 (2.2) 3 7.5kHz 11.0 10.0
5 (3.7) 3 7.5kHz 17.5 16.5
400V
3-phase
0.25 (0.2) 3 7.5kHz 1.2 1.0
0.5 (0.4) 3 7.5kHz 1.8 1.6
1 (0.75) 3 7.5kHz 3.4 3.0
2 (1.5) 3 7.5kHz 4.8 4.0
3 (2.2) 3 7.5kHz 5.5 4.8
4 (3.0) 3 7.5kHz 7.2 6.3
5 (3.7) 3 7.5kHz 9.2 7.6
(1) Reduce continuous output current by changing carrier frequency to a
setting of 4 (10 kHz) for 200V class inverters (size >
1.5kW) and all 400V
class inverters. Refer to the table above for the reduced current.
[Operation Condition]
• Input power supply voltage: 3-phase 200 to 230V (200V class)
Single-phase 200 to 240V (200V class)
3-phase 380 to 460V (400V class)
• Ambient temperature: 14 to 122
o
F (-10 to +50
o
C)
(2) If the wiring distance is long (approx. 50 meters), reduce the inverter car-
rier frequency as described below.
Wiring Distance between
Inverter and Motor
Up to 50m Up to 100m More than 100m
Carrier frequency
(n46 setting)
10kHz or less
(n46=1, 2, 3, 4,
7, 8, 9)
5kHz or less
(n46=1, 2,
7, 8, 9)
2.5kHz or less
(n46=1, 7, 8, 9)
To Next Page
