Yealink MP58 Recovery Guide

Recovery Mode on Yealink IP phones
10
The IP phone must be configured in the same subnet as the TFTP server.
Note
3. Press to complete the recovery mode.
The IP phone will download and upgrade the firmware from the TFTP server. After upgrading, the IP
phone will initialize successfully and get ready for use.
The LCD screen prompts “Initializing…Please Wait” when upgrading successfully.
Note
4. If the IP phone fails to upgrade, the LCD screen will indicate the failure. You need to check and make
sure:
 The connectivity between the TFTP server and the IP phone works well.
 The resource files are correctly renamed and placed to the TFTP root directory.
 Repeat the recovery mode procedures to try again.
The LCD screen prompts “Update Fail…Please reboot” when failing to upgrade:
You need to press (for SIP-T19(P) E2 IP phones), (for SIP VP-T49G IP phones), (for
SIP-T58A/T57W IP phones), (for MP56/MP58/VP59 IP phones), (for MP54 IP phones)
(for SIP-T3 IP phones) to complete the recovery mode since there is no key.
For MP54 IP phones, you need to press / / as up/down/left/right
navigation key.
For CP860/CP920 IP phones, you need to press the left or right side of the volume key
( )/( or ) as the left or right navigation key.
For SIP VP-T49G IP phones, you need to press / / / as up/down/left/
right navigation key.
For MP56/MP58/VP59/SIP-T58A/T57W IP phones, you need to press / / as
up/down/left/right navigation key.
…. Initializing ….
Please Wait
Welcome
IP Address:
Netmask:
IP Gateway:
TFTP Server:
10. 2. 11.124
255.255.255. 0
10. 2. 11.254
10. 2. 11.123

Yealink MP58 Specifications

General

Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Number of simultaneous touchpoints	5
Graphical user interface (GUI) language	Multi
Caller ID	-
Lines quantity	- lines
Phonebook capacity	- entries
Mounting	Desk
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Bluetooth version	4.2
Security algorithms	HTTPS, MD5, TLS
Networking standards	IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	IPv4/IPv6, SNTP
Compatible products	Skype for Business
Operating system version	9.0
Operating system installed	Android
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	G.722, AGC, G.729A, AJB, G.729B, PLC, SILK, G.723.1, VAD, G.711alaw, G.726, iLBC, CNG, G.711ulaw
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Master (outer) case width	303 mm
Master (outer) case height	342 mm
Master (outer) case length	680 mm
Master (outer) case weight	9100 g
Harmonized System (HS) code	85171800
Master (outer) case net weight	8500 g
Quantity per master (outer) case	5 pc(s)
USB output current	0.5 A
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Power consumption (typical)	7 W
Power consumption (Power over Ethernet (PoE))	7.6 W
Certification	CE, FCC, RoHS, ISO 9001, CCC, REACH

Weight and Dimensions

Depth	196 mm
Width	259 mm
Height	164 mm
Package depth	324 mm
Package width	293 mm
Package height	128 mm
