Yealink SIP-T19P Quick Start Guide

E
N
G
L
I
S
H
2
2. Connect the handset and optional headset, as shown below:
Note:
The headset should be purchased separately.
3. Connect the network and power, as shown below:
You have two options for network and power connections. Your system administrator will advise
you on which one to use.
A
B
PC Connection
(Optional)
Power Adapter
(DC 5V)
PC Connection
(Optional)
IEEE 802.3af compliant
PoE Hub/Switch
PoE (Power over
Ethernet) Option
AC Power Option
Note:
PoE is only applicable to the SIP-T19P IP phone. If inline power (PoE) is provided, you don’t need to connect
the power adapter. Make sure the hub/switch is PoE-compliant.
Startup
After the IP phone is connected to the network and supplied with
power, it automatically begins the initialization process.
After startup, the phone is ready for use. You can configure the
phone via web user interface or phone user interface.
Welcome
Initializing... please wait

Yealink SIP-T19P Specifications

General

Speakerphone	Yes
Voice codecs	CNG, G.711, G.723, G.726, G.729ab, VAD
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Front camera	No
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	1
Security algorithms	802.1x RADIUS, AES, HTTPS
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3u
Supported network protocols	IPv6
Ethernet LAN (RJ-45) ports	2
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	185 mm
Height	143 mm
