Yealink UVC40 Quick Start

4
1. Press the power button on the bottom left of MCore Pro, and the Microsoft Windows 10 IoT
Enterprise Edition operating system will be automatically loaded after starting MCore Pro.
Note: When starting up the system for the rst time, you need to connect a mouse to complete the
initial conguration. We recommend using the wireless mouse and keyboard kit.
After the system is initialized, you can use MTouch E2 to complete the system login and settings,
and the device will automatically start the Microsoft Teams conference system application and
enter the setting page.
2. Select the check box on the EULA page, and then tap Next.
3. Enter the account, the password on the Account page, and then tap Next. Supports Microsoft
Teams Rooms or Skype® for Business accounts.
4. On the Advanced page, congure the domain and tap Next.
5. Tap Finish to complete the setup wizard.
1. Connect the WPP30 to the USB port of the MTouch E2.
When pairing, the LED indicator of WPP30 is orange. And the
pairing is successful, the LED indicator turns green breathing light.
2. Connect the paired WPP30 to the USB-A/USB-C port on your PC.
3. On the WPP30, press the presentation button to share full screen.
1. Tap More > to enter the Camera Control page.
5
Initial Setup
6
Features
Wireless Sharing
Control UVC40 Camera Position
1$
WPP30

Yealink UVC40 Specifications

General

Megapixel	20 MP
Camera type	Single camera
Sensor type	CMOS
Image sensor size	- \
Optical sensor size	1/1 \
Field of view (FOV) angle	133 °
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina
Windows operating systems supported	Windows 10, Windows 7
Built-in microphone	Yes
HD type	-
Maximum frame rate	60 fps
Maximum video resolution	- pixels
Product color	Black
USB cable length	7 m
Product type	Personal video conferencing system
Certification	CE
Number of cameras	1
Number of persons	- person(s)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	100 - 240 V
DC output current	0.7 A
DC output voltage	48 V
Power source type	DC
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Number of microphones	8
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	68 mm
Width	600 mm
Height	82 mm
Weight	2560 g
