Yealink UVC86 Quick Start Guide

1



Package Contents
UVC86
7m
USB Cable
7.5m
Ethernet Cable
Power Adapter
48V/0.7A
VCR20
Remote Control
AAA
Battery×2
Cable Tie× 5
Velcro
(on the bracket)
Mounting Bracket
and Accessories
Quick Start Guide
1. The USB cable in the UVC86 single-product package is 7m, and 2.5m in the UVC86 bundle package.
2. Before you begin, please use Yealink Room Connect software for lens calibration.
2. We recommend that you use the accessories provided or approved by Yealink. The use of unapproved
third-party accessories may result in poor performance.
UVC86 Installation
• Mount on top of a display
Choose the following installation method when the thickness of the TV is between 0mm and 50mm.
Pay attention to the direction
of the bracket.
• Put on a Flat Surface
You can put the UVC86 on the conference table, and make sure that the angle of inclination of the UVC86
is not more than 5 degrees to ensure proper operation.
X 4
X 4
X 5
E
N
G
L
I
S
H

Yealink UVC86 Specifications

General

Microphone in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cables included	USB
USB cable length	7 m
Megapixel	8 MP
Camera type	Dual camera
Digital zoom	1.7 x
Optical zoom	12 x
Vertical field of view	78 °
Horizontal field of view	110 °
Number of camera presets	9
Pan range	-100 - 100 °
Mounting type	Stand
Product color	Black
Tilt angle range	-90 - 40 °
Tracking modes	Presenter mode
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Input current	0.7 A
DC input voltage	48 V
Power source type	AC
AC input frequency	100 - 240 Hz
Maximum frame rate	30 fps
Maximum video resolution	3840 x 2160 pixels
Harmonized System (HS) code	85258900

Weight and Dimensions

Depth	156 mm
Width	210 mm
Weight	3270 g
