32. 33.
ITEM# PART # DESCRIPTION QTY
1 N/A SB5 FRONT TRIANGLE ASSEMBLY
1.1 N/A SB5 FRONT TRIANGLE 1
1.2 300070006 ICE AXE HEAD BADGE 1
1.3 300060072 YETI SEAT CLAMP STANDARD 1
1.4 300040495 FRONT TRIANGLE PORT COVER 1
1.5 300030291 (M4 X 0.7 X 10MM) BLACK 3
1.6 400100144 DT PROTECTOR 1
1.7 300030010 BOLT-CAP H20 (M5 X 0.8 X 16MM) 2
1.8 300030148 WASHER 5.1X8.9X1MM 2
2 N/A SB5 SWING ARM ASSEMBLY
2.1 N/A SB5 SWING ARM 1
2.2 300060073 12X148 HANGER STD KIT GEN3 1
2.2.1 300060074 12X148 HANGER STANDARD GEN3 1
2.2.2 300060075 12X148 HANGER CAP GEN3 1
2.3 400100141 SB5 CS/SS PROTECTOR 1
2.4 400100142 SB5 CHAINSUCK GUARD 1
2.5 400100143 SB5C CS LOWER PROTECTOR 1
3 200020201 FOX LINEAR BEARING 74.0MM ASSEMBLY
4 N/A SHOCK ASSEMBLY SB5
4.1 N/A FOX FLOAT DPS 210MM X 50MM 1
4.2 N.A FOX MOUNT KIT 40.0MM 1
4.3 N/A FOX MOUNT KIT 25.0MM 1
5 N/A SB5 FRAME ASSEMBLY PARTS
5.1A 200020266 SB5 ALLOY LINK (W/BEARINGS) 1
5.1C 200020260 SB5 CARBON LINK (W/BEARINGS) 1
5.1.1A 200020264 SB5 ALLOY LINK 1
5.1.1C 200020261 SB5 CARBON LINK 1
EXPLODED VIEW PARTS LIST
ITEM# PART # DESCRIPTION QTY
5.1.2 300020050 BEARING 6900-2RS-MAX 22X10X6 4
5.1.3 300030281 SPACER 10MM X 29.0MM 1
5.1.4 300030282 SPACER 10MM X 6.0MM 1
5.2 300020049 INNER RACE EXTENDER 10MM 4
5.3 300040484 COLLET AXLE 10X53.5X13.0 M10X1.0 1
5.4 300040486 COLLET WEDGE SUB-ASSEMBLY 10MM 2
5.4.1 300030284 COLLET BOLT M5X.8 1
5.4.2 300030283 COLLET WEDGE 10MM 1
5.4.3 300040482 SPIRAL RETAINING RING 1
5.5 300030286 COLLET NUT M10X1X12MM 1
5.6 300040483 COLLET AXLE 10X30.5X9.0 M10X1.0 1
5.7 300030287 COLLET NUT M10X1X8MM 1
5.8 300040485 COLLET AXLE 15X52.5SX13.0T M15X1.5 1
5.9 300040454 COLLET WEDGE SUB-ASSEMBLY GEN2 1
5.9.1 300030268 COLLET BOLT M8X1.25 1
5.9.2 300030267 COLLET WEDGE 15MM 1
5.9.3 300040450 SPIRAL RETAINING RING 1
5.10 300030285 COLLET NUT M15X1.5X12MM 1
5.11 300030153 BOLT-TI-FEMALE 8.0X34.0MM GEN2 1
5.12 300030069 WASHER 8.5X12.5X0.5 MM 2
5.13 300030151 BOLT TI MALE M6X12.0MM 3
5.14 300030062 WASHER 6.5X12.5X0.5 MM 2
5.15 300030289 BOLT-TI-STUD 8.0X49.0MM 1
5.16 300030057 BOLT-CAP (M6 X 1 X 20 MM) 4
5.17 300030214 WASHER (10X6.2X1MM) 4
