Appendix 1. Signal Conditioner Models
App.1-1
TI 33K01B10-50E
Appendix 1. Signal Conditioner Models
The following tables list the signal conditioner cards and nests used in CENTUM V and -XL
systems.
(1) CENTUM V System
Type Model Name
Signal conditioner nest
CNC CENTUM I/O nest
CNM CENTUM MAC2 connection I/O nest
Input signal conditioner card
CM1 mV input card
CT5 Thermocouple input card
CR5 RTD input card
CS1 Potentiometer input card
CH1 Input isolator card (1-5 V input)
CH2 Input isolator card (0.2-1 V input)
CH5 Input isolator card (1-5 V input, w/square root extraction)
CA1 2-wire transmitter input card
CA5 2-wire transmitter input card (w/square root extraction)
CP1 Pulse-train input card
Output signal conditioner card
CC0 Control output isolator card
CA0 Output isolator card (4-20 mA output)
CH0 Output isolator card (1-5 V output)
Through card CX1 I/O through card
