Appendix 3. Tuning Parameter Differences
App.3-1
TI 33K01B10-50E
Appendix 3. Tuning Parameter
Differences
It may be necessary to reset the tuning parameters between the existing CENTUM V or
CENTUM-XL and CENTUM VP system. The following pages show the data types of the tuning
parameters that are different in the CENTUM V, CENTUM-XL and CENTUM VP systems. In
addition, tuning parameters marked with a number in the conversion equation column require
conversion. See the table “Equations for Tuning Parameters Requiring Conversion” at the end of
this chapter.
CENTUM V and CENTUM VP
Table Tuning Parameters Difference between CENTUM V and CENTUM VP(1/5)
CENTUM V
Instrument type
CENTUM VP
Function block
CENTUM V
Data type
CENTUM VP
Data item
Conversion
equation
Common – ALRM, AS, ASUB ALRM (*25)
Common – LOOP, LS, LSUB MODE, BSTS (*26)
Common – SM(EOPS indicates as SUM) SUM
Common(7DC-*) – K1 Control direction: DR
Common – K2(EOPS indicates as SU) (None)
Common – K3(EOPS indicates as SM) (None)
Common – K5 RAW
Common – AV (None)
Common – SD (None)
Common – RD (None)
Common(7CM-*) – PV CPV
Common(7CM-*) – K4 GAIN
Common – MH, ML, MV Ditto as left (*1)
Common(7DC-*) – P, I, D Ditto as left (*20)
7PV PVI No difference except "Common"
7PV-DV PVI-DV No difference except "Common"
7DC-D5/N5 PID BS GW (*3)
CS CK
7DC-D6/N6 PID BS GW (*3)
CS CK
7DC-B5 PID-BSW BS BIAS (*4)
CS LK (*3)
7DC-D3 PD-MR BS MR (*1)
CS CK
K7 CALC (*1)
7DC-C2 ONOFF CS CK
7DC-C3 ONOFF-G BS DB (*3)
CS CK
7DC-C9 PID-TP BS GW (*3)
