Appendix 3. Tuning Parameter Differences
App.3-2
TI 33K01B10-50E
CENTUM V
Instrument type
CENTUM VP
Function block
CENTUM V
Data type
CENTUM VP
Data item
Conversion
equation
7DC-D9 PI-BLEND VL VL (*2)
D TK
BS RP (*4)
DL DL (*2)
K4 RST (*5)
7ML-ND MLD No difference except "Common"
7ML MLD-PVI No difference except "Common"
7ML-SW MLD-SW BS BIAS (*7)
CS GAIN
SH SSH
SL SSL
7ML-XN MLD-SW BS BIAS (*7)
CS GAIN
DL RP (*6)
SH SSH
SL SSL
7RL VELLIM K1 DMVP (*8)
K2 DMVM (*8)
K3 TU (*9)
K4 BPSW
7RS RATIO BS + CS BIAS (*10)
K7 CALC (*1)
DL RP
RS SSH
7SS-A AS-H/M/L SV SW
PH SWH
PL SWL
7SS-S SS-H/M/L SV SW
PH SWH
PL SWL
7RD SS-DUAL K4 SW
K6 RV1
K7 RV2
7SW-33 SW-33 SV SW
PH SWH
PL SWL
7SW-D7/DE DSW-16 PV CPV
SV SW
D1 to D9,
DA to DE
SD01 to SD09,
SD10 to SD14
7DS-ND DSET PH SVH
PL SVL
Mar. 27, 2015-00
Table Tuning Parameters Difference between CENTUM V and CENTUM VP(2/5)
