Appendix 4. Functions Related to Upgrade
App.4-2
TI 33K01B10-50E
Table Functions Related to Upgrade Before R5.03.00 (2/7)
Item Function
CENTUM V or
CENTUM-XL
CENTUM VP Measures
Sequence
table
Nonlatched
(L-shaped)
output OFF and
N operations
in nonlatched
step sequence
in processing
timing TC
(periodic
execution or
execution only
when conditions
are changed)
If conditions are false,
L-shaped outputs are
turned off.
Even if conditions are
false, L-shaped outputs
are not turned off.
If conditions are false,
an L-shaped output is
off provided that Yes in
[CENTUM-XLCompatible
Sequence Tables] is
speciedintheFCS
property.
If conditions are true,
an L-shaped output is
off when an N operation
is executed on the
L-shaped output.
If an N operation is
executed on an L-shaped
output, the output is
ignored even though
conditions are true.
When an N operation is
executed on an L-shaped
output, the output is
turned off if conditions are
true provided that Yes in
[CENTUM-XLCompatible
Sequence Tables] is
speciedintheFCS
property.
“N” operation of
pulse-shaped
(P-shaped)
output
If an N operation is
executed on a P-shaped
output, a P-shaped
output that has been
turned on is turned off.
Even if an N operation is
executed on a P-shaped
output, its operation is
ignored.
If an N operation is executed
on a P-shaped output,
P-shaped outputs that are
turned on are off when Yes
in[CENTUM-XLCompatible
Sequence Tables] has
beenspeciedintheFCS
property.
Action execution
timing in step
00 (When 1.00
steps and the
execution steps
are on the same
table)
Carry out the processing
in the following steps:
1) Evaluate condition
signals in step 00 and
the execution step.
2) Execute action signals
in step 00 and the
execution step
Carry out the processing
in the following steps:
1) Evaluate the condition
signal in step 00 and then
execute the action signal.
2) Evaluate the condition
signal in the execution
step and then execute the
action signal.
SpecifyYesin[CENTUM-
XL Compatible Sequence
Tables] in the FCS property
and then execute the
following steps:
1) Evaluate condition
signals in step 00 and in the
execution step.
2) Execute action signals in
step 00 and the execution
step
Action execution
timing in step 00
(If step 00 is on
the expansion
source table and
the execution
step is on the
extension
destination
table:
Carry out the processing
in the following steps:
1) Evaluate the condition
signal in step 00 and
then execute the action
signal.
2) Evaluate the condition
signal in the execution
step and then execute
the action signal.
Carry out the processing
in the following steps:
1) Evaluate the condition
signal in step 00 and then
execute the action signal.
2) Evaluate the condition
signal in the execution
step and then execute the
action signal.
SpecifyYesin[CENTUM-
XL Compatible Sequence
Tables] in the FCS property
and then execute the
following steps:
1) Evaluate the condition
signal in step 00 and then
execute the action signal.
2) Evaluate the condition
signal in the execution step
and then
Step changes in
own table and
THEN/ELSE
priority order
If THEN/ELSE is in
the execution step,
follow the description
of the THEN/ELSE in
the execution step to
shift steps. If there is
no THEN/ELSE in the
execution step, shift to
a step to which a step
name has been set.
Shift to a step name set
in the execution step and
execute to set steps. Then
follow the description of
THEN/ELSE in the set
step to shift steps.
If THEN/ELSE is in the
execution step, setting the
steps to their own table is
invalid, step is then shifted
to THEN/ELSE in the
execution step when Yes in
[THEN/ELSEisprecedent
in the action of sequence
tablehasbeenspeciedin
the FCS property. If THEN/
ELSE is not in the execution
step, shift to a step to which
a step name is set.
Mar. 27, 2015-00
