YOKOGAWA Centum-XL User Manual

Appendix 3. Tuning Parameter Differences
App.3-6
TI 33K01B10-50E
CENTUM-XL and CENTUM VP
Table Tuning Parameters Difference between CENTUM-XL and CENTUM VP(1/6)
CENTUM-XL
Instrument type
CENTUM VP
Function block
CENTUM-XL
Data type
CENTUM VP
Data item
Conversion
equation
Common – ALRM, AS, ASUB ALRM (*25)
Common – LOOP, LS, LSUB MODE, BSTS (*26)
Common – SU, SM None
(combined into SUM)
Common – CALC Ditto as left (*1)
Common – MH, ML Ditto as left (*1)
Common – MV, PMV Ditto as left (*1)
Common – OPHI, OPLO Ditto as left (*1)
PVI PVI No difference except "Common"
PVI-DV PVI-DV No difference except "Common"
PID PID P, I, D Ditto as left (*20)
BS GW (*3)
CS CK
PI-HLD PI-HLD BS GW (*3)
CS CK
SW CSW
PID-BSW PID-BSW P, I, D Ditto as left (*20)
BS GW (*3)
CS LK
ONOFF ONOFF CS CK
ONOFF-G ONOFF-G BS DB (*3)
CS CK
PID-TP PID-TP P, I, D Ditto as left (*20)
BS GW (*3)
CS CK
PD-MR PD-MR P, D Ditto as left (*20)
BS MR (*1)
CS CK
PI-BLEND PI-BLEND DL, VL Ditto as left (*2)
D TK
BS RP (*4)
SW RST (*5)
PID-STC PID-STC PB P
TI I
TD D
MLD MLD
No difference except "Common"
MLD-PVI MLD-PVI No difference except "Common"
MLD-SW MLD-SW DL RP (*6)
BS BIAS (*7)
CS GAIN
SH SSH
SL SSL
Mar. 27, 2015-00
