YOKOGAWA Centum-XL User Manual

Appendix 3. Tuning Parameter Differences
App.3-7
TI 33K01B10-50E
CENTUM-XL
Instrument type
CENTUM VP
Function block
CENTUM-XL
Data type
CENTUM VP
Data item
Conversion
equation
VELLIM VELLIM DMVP, DMVM Ditto as left (*8)
TU TU (*9)
SW BPSW (*9)
SH SSH
SL SSL
RATIO RATIO CALC CALC (*1)
DL RP
BS + CS BIAS (*10)
RS SSH
AS-H/M/L AS-H/M/L PH SWH
PL SWL
SV SW
SS-H/M/L SS-H/M/L PH SWH
PL SWL
SV SW
SS-DUAL SS-DUAL PV1, PV2 RV1, RV2
SW-33 SW-33 SV SW
PH SWH
PL SWL
SW-91 SW-91 SV SW
PH SWH
PL SWL
DSW-14 DSW-16 PV CPV
SV SW
DSET DSET PH SVH
PL SVL
DSET-PVI DSET-PVI No difference except "Common"
PG-L13/S13 PG-L13 RS SH - SL
Y01 to Y14 Ditto as left (*1)
BSZ ZSTR
BEZ ZEND
LAG LAG PV CPV
LD LD PV CPV
RAMP RAMP I STEP
LDLAG LDLAG PV CPV
DLAY DLAY PV CPV
D SMPL
SW RST (*5)
DLAY-C DLAY-C PV CPV
D SMPL
SW RST
Mar. 27, 2015-00
Table Tuning Parameters Difference between CENTUM-XL and CENTUM VP(2/6)
