WhentherelayissettoANDlogic
ACK ACK
Alarm A
Occurrence
Alarm B
Occurrence
Release
Release
Relay
Activated
Deactivated
Alarm B has occurred, so now all alarms have occurred.
This causes the relay to be activated.
