 ResettingtheRelativeTimer
If the event is set to output relay, internal switch, match time timer, or alarm, the
resetting of the timer is not considered a timeout. (The action is not executed even if
the timer is used as an event.)
 LoadingtheSetup
Can be specified as an action only when the event is set to remote control input.
Loads the setup data file, LOAD1.PDL, LOAD2.PDL, or LOAD3.PDL, in the root
directory of the CF card into the DX and updates the DX settings.
You must create a setup file and save it to the CF card in advance.
 EventTriggerOperation
When the event is set to output relay, internal switch, or alarm
If the output relay is activated, the internal switch is 1, or the alarm is occurring during
memory sampling, the event trigger is always activated. However, the number of times
the trigger is activated depends on the event data mode (single or repeat).
 TimeAdjustment
 Timeadjustmentcanbespecifiedasanactiononlywhentheeventissettoremote
controlinput.TheinternalclockoftheDXisadjustedtothenearesthourthrough
remote control input.
 • OperationWhenMemorySamplingIsStopped
DifferencefromtheNearestHour Operation
00 min 00 s to 01 min to 59 s Truncates the minutes and seconds.
Example: 10 hours 01 min 50 s becomes 10 hours 00 min 00 s.
02 min 00 s to 57 min to 59 s The time is not changed.
58 min 00 s to 59 min to 59 s Rounds up the minutes and seconds.
Example: 10 hours 59 min 50 s becomes 11 hours 00 min 00 s.
 • OperationduringMemorySampling
If the time difference between the time the remote control signal is applied and
the nearest hour is within the preset time, the time is gradually corrected. If the
time difference exceeds the preset time but is less than two minutes, the time is
immediately corrected. If the time difference is two minutes or more, the time is not
corrected. For details, see section 1.10.
OnDXswiththe/AS1AdvancedSecurityOptionandReleaseNumber4or
Later
Event ConditionsforExecution
Output relay, internal switch,
timer, match time timer, and
alarm
When these events occur, their corresponding actions are
performed regardless of the user privilege settings and whether
users are logged in.
User Key The same as the key operation itself. In setting mode, memory
start cannot be performed.
Event edge switch and event
level switch
The same as the key operations themselves. Even in setting
mode, memory start cannot be performed.
Remote When a remote control signal is received, the corresponding
action is performed regardless of the user privilege settings
and whether users are logged in. In setting mode, memory start
cannot be performed.
