DLM 2000
DLM 2000DLM 2000
Series
SeriesSeries
lexibility
Switch between analog and logic channels
sability
Compact & intuitive operation
Easy-to-Use &
Easy-to-See
Easy to use. Portrait body + large
screen makes display easy to see.
Flexible MSO input
Four channels is not sufcient to view the functioning of digital control circuits. The DLM2000 series converts 4 ch of analog input to 8-bit
logic, and functions as a 3 ch analog + 8-bit logic MSO (mixed signal oscilloscope).
The performance of up to 11 inputs by converting to logic
Using logic input, up to 11 input signals can be observed simultaneously as 3 ch of analog and 8-bit logic. It is not
only possible to use logic input for observation of data and control signals, or as a trigger source, but also for logic
input analysis of I
2
C, SPI and some other serial busses.
4 ch analog 3 ch analog + 8-bit logic
Example of logic
probe connection
Logic probe for the DLM2000
Large screen in a compact body
Footprint is approximately 2/3 the
size of an A4 size paper (depth of
approximately 200 mm)
Fast data processing with ScopeCORE
With our proprietary ScopeCORE fast data processing IC, real time display
is possible even when simultaneously measuring multichannel signals of 11
inputs.
Measured values can
be accurately read on
the 0.1 div sub grid
display.
We elevated the large
(8.4-inch) LCD screen up
into the line of sight. Also,
the portrait format saves
space on the desk or test
bench. A compact “personal
oscilloscope” designed for
easy viewing and ease of
use.
ScopeCORE fast
data processing IC
FU
Switch
4-way selector button
For moving the cursor
up/down/left/right
Vertical position and
vertical scale knobs
Horizontal position and
horizontal scale knobs
Trigger control keys and
level knob
Zoom control keys and
magnication knob
Jog shuttle
For changing values and
moving cursors
USB peripheral
connection terminal
Logic input connector
