YOKOGAWA DX1012 User Manual

74 IM 04L41B01-02E
Communication (Serial)
Setup Item Selectable Range or Selections Default Value Setting
Basic settings
Baud rate 1200/2400/4800/9600/19200/38400 9600
Data length 7/8 8
Parity Odd/Even/None Even
Handshaking Off:Off/XON:XON/XON:RS/CS:RS Off:Off
Address 1 to 99 1
Protocol Normal/Modbus/Modbus-M Normal
Modbus master > Basic settings
Read cycle 125ms/250ms/500ms/1s/2s/5s/10s 1s
Timeout 125ms/250ms/500ms/1s/2s/5s/10s/1min 1s
Retrials Off/1/2/3/4/5/10/20 1
Inter-block delay Off/5ms/10ms/15ms/45ms/100ms Off
Auto recovery Off/1min/2min/5min/10min/20min/30min/1h 2min
Modbus master > Command settings
Master command number 1-8/9-16 1-8
1 to 16 Off/R/R-M/W/W-M Off
First Depends on the command type. –
Last Depends on the command type. –
Addr. 1 to 247 1
Regi. Numerical value 30001
Type INT16/UINT16/INT32_B/INT32_L/UINT32_B/ INT16
UINT32_L/FLOAT_B/FLOAT_L
Status relay
Setup Item Selectable Range or Selections Default Value Setting
Memory/Media status On/Off Off
Measurement error On/Off Off
Communication error On/Off Off
Memory stop On/Off Off
End
Setup Item Selectable Range or Selections Default Value Setting
Do you want to store and Yes/No/Cancel –
make the new settings take effect?
Setup Items and dDefault Values
