n FLXA21 Dimensions and Mounting
44.9
137
1
20.2
151
22.5
80
4-M6 depth 5
(For sensor 2 cable)
For sensor 1 cable
For power supply
For grounding cable
137
80
144
24.726.526.5
141
144
FB4_01.ai
Unit: mm
Conduit Adapter (Option code: /CB4, /CD4, /CF4)
Adapter
49
(1.93")
G1/2 screw (/CB4), 1/2 NPT screw (/CD4)
M20x1.5 screw (/CF4)
Approx.
55(2.2")
Packing
Unit: mm(inch)
Nut
F0204.ai
