18
IM 12B06J03-02EN-P
Remarks:
1 No revision to this drawing without prior approval of FM.
2 Installation must be in accordance with the Canadian Electrical Code (CEC)
CSA22.1, and relevant local codes.
3 The sensor shall be installed to a certified intrinsically safe HOST with the following
maximum values: Uo= 18 V, Io = 170 mA, Po = 400 mW.
4 The sensor does not provide isolation from earth. Installers shall take necessary
measures to prevent the possibility of sparking resulting from differing earth
potentials between the sensors and interconnecting equipment. This can be realized
for example by selecting interconnecting equipment which provides input-to-output
and input-to-earth isolation up to 500 V rms.
5 Sensor Model code:
Table 5:
Two alphanumeric characters identifying the
length of the permanent cable, each character
from 0 to 9
VP Connector without ID-chip
VS Connector with ID-chip
Temperature sensor
+ Region:
T1 Pt1000, IS for ATEX/IECEx, FM-US,
FM-CAN
NPT PPS body/Tapered Thread/
Dome shaped
FSM PPS body/Tapered Thread/Flat Surface
FTD PVDF body/Tapered Thread
Dome shaped
Up to ten alphanumeric characters
(A to Z, 0 to 9 or hyphen)
6 WARNING－POTENTIONAL ELECTROSTATIC CHARGING HAZARD SEE
INSTRUCTIONS
pH sensors containing accessible plastic parts and/or external conductive parts, must
be installed and used in such a way, that dangers of ignition due to hazardous
electrostatic charges cannot occur, especially in the case that the process medium is
non-conductive.
AVERTISSEMENT
DANGER POTENTIEL DE CHARGES ÉLECTROSTATIQUES VOIR LES
INSTRUCTIONS
Les sondes de pH contenant des pièces en plastique accessibles et / ou des pièces
conductrices externes doivent être installées et utilisées de manière à éviter tout
risque d'inflammation dû à des charges électrostatiques dangereuses, en particulier
dans le cas où le fluide de procédé n'est pas conducteur.
