6
IM 12D06D05-01E
min.185 (7.25 " )
min.195(7.75
"
)
138(5.43 " )
138
(5.43
" )
M6
M6
M5
138
(5.43
" )
+1
0
138 (5.43
"
)
+1 0
Figure 3-2. Option /PM: panel mounting diagram
Figure 3-3. Option /U: wall and pipe mounting diagram
2" ND. pipe
pipe mounting
(horizontal)
pipe mounting
(vertical)
wall mounting
15
(0.6")
35
(1.38")
13
(0.51")
4x Ф6.5
(0.26")
4x Ф10
(0.4")
200
(7.87")
70
(2.75")
154.5
(6.08")
80
(3.15")
80
(3.15")
Unit: mm (inch)
(Note) When option code "/UM"isspecified,universalpipe/wall/pannelmountingkitaresupplied-
--same as option code "/U" and "/PM" both specified.
