YOKOGAWA ProSafe-RS Technical Information

App.1-16
TI 32S01J30-01E
Appendix 1. US (FM) NI/Canada (FM) NI/IECEx Ex “ec”/ECAS-EX Ex “ec”
Yokogawa Electric Corporation
Model
ProSafe-RS/ProSafe-RS Lite
Title
Control drawing
No.
NFM014-A13
Page
15
Revision
78
Nonincendive Field Wiring Parameters (Output parameters) (*1)
Model
Voc
(
V
)
Isc
(
mA
)
Ca
(
μF
)
La
(
mH
)
Remarks
SAI143
L1AI143
Redundant 26.4 26 0.13 10
-2-wire transmitter input
-Included terminal block and terminal board
but excluded cable.
Single 26.4 26 0.13 10
Redundant 12.2 0.14 0.01 1
-Cable coming out detection
(Wires connected to Pin No. 1 and 40)
-Included terminal block and terminal board
but excluded cable.
Single 12.2 0.07 0.01 1
SAV144
L1AV144
Redundant 10 1.2 0.01 1
-Cable coming out detection
(Wires connected to Pin No. 1 and 40)
-Included terminal block and terminal board
but excluded cable.
Single 10 0.6 0.01 1
SAI533
L1AI533
Redundant 18.9 23 0.16 10
-Output
-Included terminal block and terminal board
but excluded cable.
Single 18.9 23 0.16 10
Redundant 10 220 0.01 1
-Cable coming out detection
(Wires connected to Pin No. 1 and 40)
-Included terminal block and terminal board
but excluded cable.
Single 10 110 0.01 1
SDV144
L1DV144
Redundant 11.6 1.4 0.01 1
-Cable coming out detection
(Wires connected to Pin No. 1 and 50)
-Included terminal block and terminal board
but excluded cable
Single 11.6 0.7 0.01 1
SDV531
L1DV531
Redundant 11.6 220 0.01 1
-Cable coming out detection
(Wires connected to Pin No. 1 and 50)
-Included terminal block and terminal board
but excluded cable
Single 11.6 110 0.01 1
SDV541
L1DV541
Redundant 11.6 220 0.01 1
-Cable coming out detection
(Wires connected to Pin No. 1 and 50)
-Included terminal block and terminal board
but excluded cable
Single 11.6 110 0.01 1
SDV521
L1DV521
Redundant 11.6 220 0.01 1
-Cable coming out detection
(Wires connected to Pin No. 1 and 50)
-Included terminal board but excluded cable
Single 11.6 110 0.01 1
SDV53A
L1DV53A
Redundant 11.6 220 0.01 1
-Cable coming out detection
(Wires connected to Pin No. 1 and 50)
-Included terminal board but excluded cable
Single 11.6 110 0.01 1
SAT145
L1AT145
Redundant 1.5 1.0 0.01 0.14
-RJC input
-Included terminal board but excluded cable
Single 1.5 1.0 0.01 0.14
Redundant 6.0 3.0 0.45 3.74
-TC/mv input (Burn out)
-Included terminal board but excluded cable
Single 6.0 3.0 0.45 3.74
Redundant 6.0 20.0 0.01 0.14
-Cable coming out detection
(Wires connected to Pin No. 1 and 50)
-Included terminal board but excluded
cable.
Single 6.0 20.0 0.01 0.14
SAR145
L1AR145
Redundant 6.0 50.0 0.20 1.32
-RTD input
-Included terminal board but excluded
cable.
Single 6.0 50.0 0.20 1.32
Redundant 6.0 70.0 0.01 0.14
-Cable coming out detection
(Wires connected to Pin No. 1 and 50)
-Included terminal board but excluded
cable.
Single 6.0 70.0 0.01 0.14
*1 These parameters are applied to all modes of each model if the mode is not otherwise
remarked.
Dec. 3, 2021-00
