YOKOGAWA ProSafe-RS Technical Information

App.1-17
TI 32S01J30-01E
Appendix 1. US (FM) NI/Canada (FM) NI/IECEx Ex “ec”/ECAS-EX Ex “ec”
Yokogawa Electric Corporation
Model
ProSafe-RS/ProSafe-RS Lite
Title
Control drawing
No.
NFM014-A13
Page
16
Revision
78
Nonincendive Field Wiring Parameters (Input parameters) (*1)
Model
Vmax
(
V
)
Imax
(
mA
)
Ci
(
μF
)
Li
(
μH
)
Remarks
SAI143
L1AI143
Redundant 26.4 26 0.008 20
-4-wire transmitter input
-Included terminal block and terminal
board but excluded cable
Single 26.4 26 0.004 20
SAV144
L1AV144
Redundant 30 0.6 0.001 10
-Input
-Included terminal block and terminal
board but excluded cable
Single 30 0.3 0.001 10
SAT145
L1AT145
Redundant 5 1.53 0.6 10 -TC/mV input
-Included terminal board but excluded
cable
Single 5 1.53 0.6 10
SBD2D 60 20 0 0 Read
y
input DC
SBD3D 60 20 0 0 Read
y
input DC
SBD4D 60 20 0 0 Read
y
input DC
S1BB4D 60 20 0 0 Read
y
input DC
*1 These parameters are applied to all modes of each model if the mode is not otherwise
remarked.
Cable Parameter
Model
L
(
μH/m
)
C
(
pF/m
)
Remark
KS1 1.5 110
A
KB331 1.5 110
A
KB611 2.0 200
Dec. 3, 2021-00
