YOKOGAWA ProSafe-RS Technical Information

App.1-31
TI 32S01J30-01E
Appendix 1. US (FM) NI/Canada (FM) NI/IECEx Ex “ec”/ECAS-EX Ex “ec”
Yokogawa Electric Corporation
Model
ProSafe-RS N-IO
Title
Control drawing
No.
NIE009-A101
Page
9
Revision
15
(Canada)
■ Applicable standards:
CAN/CSA-C22.2 No. 0-10 (R2015)
C22.2 No. 213-17
CAN/CSA-C22.2 No.61010-1-12+Amd1-18
CAN/CSA-C22.2 No.61010-2-030:18
CAN/CSA-C22.2 No.61010-2-201:18
The models which conform to these standards are listed in the following tables of the ambient
temperature ranges.
■ Markings:
CL I DIV 2 GP ABCD T4
■ Specific Conditions of Use:
− The equipment shall be installed in a lockable metal cabinet. The suitability of the installation shall
be determined by the authority having jurisdiction.
− The Ambient Temperature ranges are as follows.
Classifications
Model
Ambient Temperature (*1)
Safety Node Units
S2NN30D-4
□0□00013
−40 to 70 °C
S2NN30D-4□0□00113
S2NN30D-4
□0□01113
S2NN30D-4
□0□02113
S2NN30D-4
□0□00213
S2NN30D-4
□0□01213
S2NN30D-4
□0□02213
S2NN30D-4
□0□01013
S2NN30D-4
□0□02013
−40 to 70 °C (altitude ≤ 2000 m)
−40 to 60 °C (2000 m < altitude ≤ 3000 m)
S2BN1D-□0130
S2BN1D-
□1130
S2BN1D-
□2130
−40 to 70 °C
When utilizing Digital output function of
S2MMM843, the total load current of all
channels is limited as shown below according
to the derating specifications due to the
ambient temperature of modules.
−40 to 40 °C: Max. 10.56 A
40 to 50 °C: Max.9.71 A
50 to 60 °C: Max.8.85 A
60 to 70 °C: Max.8 A
S2BN1D-□9130
−40 to 70 °C (*3)
When utilizing Digital output function of
S2MMM843, the total load current of all
channels is limited as shown below according
to the derating specifications due to the
ambient temperature of modules.
−40 to 40 °C: Max. 10.56 A
40 to 50 °C: Max.9.71 A
50 to 60 °C: Max.8.85 A
60 to 70 °C: Max.8 A
Dec. 3, 2021-00
