YOKOGAWA ProSafe-RS Technical Information

App.1-32
TI 32S01J30-01E
Appendix 1. US (FM) NI/Canada (FM) NI/IECEx Ex “ec”/ECAS-EX Ex “ec”
Yokogawa Electric Corporation
Model
ProSafe-RS N-IO
Title
Control drawing
No.
NIE009-A101
Page
10
Revision
15
(Continued)
Classifications
Model
Ambient Temperature (*1)
Power supply module
S2PW503-S0130
−40 to 70 °C
S2PW504-S0130
Bus interface module
S2EN501-S00130
−40 to 70 °C
S2EN501-S01130
S2EN501-S11130
S2EN501-S21130
S2EN501-S02130
S2EN501-S12130
S2EN501-S22130
S2EN501-S10130
S2EN501-S20130
−40 to 70 °C (altitude ≤ 2000 m)
−40 to 60 °C (2000 m < altitude ≤ 3000 m)
I/O module
S2MMM843-SS1130
S2MDV843-0S1130
−40 to 70 °C (*2)
When utilizing Digital output function, the total
load current of all channels is limited as
shown below according to the derating
specifications due to the ambient temperature
of modules.
−40 to 40 °C: Max. 10.56 A
40 to 50 °C: Max.9.71 A
50 to 60 °C: Max.8.85 A
60 to 70 °C: Max.8 A
S2DCV02-0
−40 to 70 °C (*2)
Terminal board A2BM4-130 −40 to 70 °C (*3)
Power Cable
S2KPB10-C
□□□
−40 to 70 °C (*2)
Bus cable
S2KLF10-1
□□2
−40 to 70 °C (*2)
*1 The ambient temperature ranges are specified for the temperature around Field Control Unit,
Base Plate or Terminal Board, and not for the temperature around each model.
*2 If it is mounted on S2BN1D-
□9130, the minimum temperature is limited to −20 °C for using
AKB331 or AKB651 together.
*3 The minimum temperature is limited to −20 °C for using AKB331 or AKB651 together.
Dec. 3, 2021-00
