YOKOGAWA UP150 Instruction Manual

IM 5E1E70-01E
6
4. PANEL CUTOUT DIMENSIONS AND
EXTERNAL DIMENSIONS
max. 61
Panel thickness
max. 47.8 max. 44.8
max. 44.8
10012
1 to 10
Unit: mm
1. General Mounting
min. 70
min. 70
45
+0.6
0
45
+0.6
0
25
25
[(N–1) × 48 + 45]
+0.6
0
+0.8
0
45
2. Side-by-side Close Mounting
(Splash-proof construction is unavailable)
N is the number of controllers.
If N
>
5, then measure the actual length.
48
48
