YOKOGAWA UP150 User Manual

IM 05C01F12-41E
16
…… …… …… …… ……
*Note
STC
Start code
0:
Program operation begins with the starting target setpoint.
1:Ramp-prioritized PV start
(program operation begins with the PV value by giving
priority to the ramp of segment 1)
2:Time-prioritized PV start
(program operation begins with the PV value by giving
priority to the time of segment 1)
0
SSP
Starting target
setpoint
0 to 100% of measured input range (scale) span
Unit:°C/°F
Min. value of
measured input range
(scale)
SP1
Target setpoint 1
0 to 100% of measured input range (scale) span
Unit:°C/°F
Min. value of
measured input range
(scale)
Use the table blow
Use the table blow
Use the table blow
Use the table blow
TM1
Segment time 1
OFF(-1) or 0.00 to 99.59 (hour,min. or min,second)
Time unit is to be set in ”TMU” parameter.
OFF(-1)
OFF(-1)
SP16
Target setpoint 16
0 to 100% of measured input range (scale) span
Unit:°C/°F
Min. value of
measured input range
(scale)
TM16
Segment time 16
OFF(-1) or 0.00 to 99.59 (hour,min. or min,second)
Time unit is to be set in ”TMU” parameter.
JC
Junction code
0: Reset
1: Hold
2: Repeat (repeat endlessly)
0
WTZ
*Note: • The setting range (scale) and unit of SPn (n=2 to 15) are same as those of SP1 (and SP16)
• The setting range (scale) and unit of TMn (n=2 to 15) are same as those of TM1 (and TM16)
■ User Setting Table of Target SP and Segment time
SP n (n=1 to 16)
n=1 n=2 n=3 n=4 n=5 n=6 n=7 n=8 n=9
n=10 n=11 n=12 n=13 n=14 n=15 n=16
TM n (n=1 to 16)
Wait zone
OFF(0) or 0 to 10% of measured input range (scale) span
OFF(0)
A1
PV event 1
setpoint
• PV alarm: Min. value of measured input range (scale) to
Max. value of measued input range (scale)
• Deviation alarm:
–100 to 100% of measured input range (scale) span
Unit: °C/°F
0: PV event
1: Time event
Max. value of
measured input range
(scale) (PV alarm)
HY1
PV event 1
hysterisis
0 to 100% of measured input range (scale) span
Unit:°C/°F
0.5% of measured
input range (scale)
span
EON1
Time event 1
on time
OFF(-1) or 0.00 to 99.59 (hour,min. or min,second)
Time unit is the same as that of the program.
OFF(-1)
EOF1
Time event 1
off time
OFF(-1) (Note) or 0.00 to 99.59 (hour,min. or min,second)
Note: Time event 1 does not stop when “OFF” is set.
OFF(-1)
EV2
Event 2 type
0: PV event
1: Time event
0
AL2
PV event 2 type
OFF(0) or 1 to 10 (see the table of PV event function list
in User's Manual for Programming/Operation)
2
A2
PV event 2
setpoint
• PV alarm: Min. value of measured input range (scale) to
Max. value of measued input range (scale)
• Deviation alarm:
–100 to 100% of measured input range (scale) span
Unit: °C/°F
Max. value of
measured input range
(scale) (PV alarm)
HY2
PV event 2
hysterisis
0 to 100% of measured input range (scale) span
Unit:°C/°F
0.5% of measured
input range (scale)
span
EON2
Time event 2
on time
OFF(-1) or 0.00 to 99.59 (hour,min. or min,second)
Time unit is the same as that of the program.
OFF(-1)
EOF2
Time event 2
off time
OFF(-1) (Note) or 0.00 to 99.59 (hour,min. or min,second)
Note: Time event 2 does not stop when “OFF” is set.
OFF(-1)
EV1
Event 1 type
0
OFF(0) or 1 to 10 (see the table of PV event function list
in User's Manual for Programming/Operation)
AL1
PV event 1 type
1
Code Setting range and unit Default User settingName
(3) Program Parameters
Numbers in ( ) are the parmeter setpoints that apply when the
communication function is used. Ex. OFF(0), ON(1)
Parameters for creating a program.
