YOKOGAWA UT150 User Manual

IM 05C01E12-41E
11
7. KEY OPERATIONS
NOTE
At power-on, the temperature controller displays the operation display ➀, but if the input range setting
remains OFF, then “IN” appears. In this case, press the key to display the input range code you want to
use, then press the key to register it. (Refer to the flowchart on page 13.)
(1) You can move between parameter setting displays using the key.
(2) To change the set value,
(i) Change the display value with the or key
(the period flashes).
(ii) Press the key to register the setting.
(3) At the operation display ➀ or ➁ , pressing the key for at least 3
seconds retrieves the operation parameter setting display.
(4) At the operation parameter setting display, pressing the key for at
least 3 seconds transfers back to the operation display ➀. Registering the
key-lock parameter LOC to “–1” retrieves the setup parameter setting
display.
(5) At the setup parameter setting display, pressing the key for at least 3
seconds transfers back to the operation display ➀.
OFF
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
Thermocouple
RTD
DC voltage
K
J
T
E
R
S
B
N
L
U
Platinel 2
Pt100
JPt100
0 to 100mV
0 to 5V
1 to 5V
0 to 10V
Unspecified
–270 to 1370°C
0.0 to 600.0°C
0.0 to 400.0°C
–199.9 to 200.0°C
–199.9 to 999.9°C
–199.9 to 400.0°C
–199.9 to 999.9°C
0 to 1700°C
0 to 1700°C
0 to 1800°C
–200 to 1300°C
–199.9 to 900.0°C
–199.9 to 400.0°C
0 to 1390°C
–199.9 to 850.0°C
0.0 to 400.0°C
–199.9 to 200.0°C
–19.9 to 99.9°C
–199.9 to 500.0°C
–300 to 2500°F
32.0 to 999.9°F
32.0 to 750.0°F
–300 to 400°F
–300 to 2100°F
–300 to 750°F
–300 to 1800°F
32 to 3100°F
32 to 3100°F
32 to 3200°F
–300 to 2400°F
–300 to 1600°F
–300 to 750°F
32 to 2500°F
–199.9 to 999.9°F
32.0 to 750.0°F
–300 to 400°F
–199.9 to 999.9°F
For example, to select
thermocouple type E (°F),
set the range code to 37.
0.0 to 100.0
0.000 to 5.000
1.000 to 5.000
0.00 to 10.00
User-scalable
● UT150/UT152/UT155 Measured Input Ranges
Input type Range
(
°C
)
Range
(
°F
)
Range code
(
°C
)
Range code
(
°F
)
When “In” appears, press the
key to display the measured input
range code you want to use, then
press the key to register it.
After this operating, the controller
shows the operating display
➀ .
NOTE
Note: If you cannot change
the parameter setting
value, check the key-lock
parameter (LOC) setting.
