SHOULD YOU REQUIRE ANY ASSISTANCE REGARDING THIS PRODUCT PLEASE CONTACT YORK DIRECTLY.
*
*
1.
ASSEMBLY INSTRUCTION
ATTACH THE STABILIZERS
Fix the front stabilizer with moving wheels
to the main frame and secure, using two
carriage bolts, washers and locknuts.
Fix the rear stabilizer to the main frame
and secure,using two carriage bolts,
washers and locknuts.
X2
X2
X2
X2
X2
MOVING
WHEEL
FRONT
STABILIZER
REAR
STABILIZER
END CAP
B
A
X2
NOTE: Make sure you fasten the nuts &
bolts securely for your safety and
comfort when exercising.
FRONT
REAR
GENERAL
REMOVE ALL THE PARTS OF YOUR MAG. ELLIPTICAL CROSS TRAINER 3100
FORM THE CARTON AND PLACE THEM ON THE FLOOR CAREFULLY.
ASSEMBLING YOUR MAG. ELLIPTICAL CROSS TRAINER 3100 IS SIMPLE.
WE RECOMMEND THAT YOU GET SOMEONE TO HELP YOU WHEN ATTACHING
THE CRANK ARMS TO THE MAIN FRAME SHAFT.
#8504-48
#8504-42
#8504-61
#8504-48
#8504-42
#8504-61
To Next Page
