FIGURE 18: BLOWER CURVE LB600
LB600
0
20
40
60
80
100
120
140
160
180 200
220 240
260
280
300
320
340 360
16 BHP
14 BHP
12 BHP
10 BHP
8 BHP
6 BHP
500 RPM
600 RPM
700 RPM
800 RPM
900 RPM
3.2
3.0
2.8
2.6
2.4
2.2
2.0
1.8
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0
AvaIlable external static pres-
sure for unit accessories and
the duct system.
Internal unit resistance based
on a dry coil plus 1"
throwaway filters.
CFM (X 100)
TOTAL STATIC PRESSURE, IWG
