5169032-UIM-C-0416
Johnson Controls Unitary Products 13
TABLE 7:
Electrical Data For Single Source Power Supply: 208/230-1-60
Air Handler Models
Heater Models
1,2
Heater
Amps
@240V
Field Wiring
Min. Circuit Ampacity
MOP.
3
208V 230V 208V 230V
18B
6HK(0,1)6500206 10 14.9 16.1 15 20
6HK(0,1)6500506 20 25.8 28.0 30 30
6HK(0,1)6500806 32 39.0 42.7 40 45
6HK(0,1)6501006 40 47.4 52.0 50 60
24B
6HK(0,1)6500206 10 14.9 16.1 15 20
6HK(0,1)6500506 20 25.8 28.0 30 30
6HK(0,1)6500806 32 39.0 42.7 40 45
6HK(0,1)6501006 40 47.4 52.0 50 60
6HK(1,2)6501306 52 60.6 66.6 70 70
30B
6HK(0,1)6500206 10 14.9 16.1 15 20
6HK(0,1)6500506 20 25.8 28.0 30 30
6HK(0,1)6500806 32 39.0 42.7 40 45
6HK(0,1)6501006 40 47.4 52.0 50 60
6HK(1,2)6501306 52 60.6 66.6 70 70
6HK(1,2)6501506 60
69.0 75.9 70 80
36B
6HK(0,1)6500206 10 16.8 18.0 20 20
6HK(0,1)6500506 20 27.6 29.9 30 30
6HK(0,1)6500806 32 40.9 44.6 45 45
6HK(0,1)6501006 40 49.3 53.8 50 60
6HK(1,2)6501306 52 62.5 68.5 70 70
6HK(1,2)6501506 60 70.9 77.7 80 80
6HK(1,2)6501806 72 84.1 92.4 90 100
6HK(1,2)6502006 80 92.5 101.7 100 110
36C
6HK(0,1)6500206 10 16.8 18.0 20 20
6HK(0,1)6500506 20 27.6 29.9 30 30
6HK(0,1)6500806 32 40.9 44.6 45 45
6HK(0,1)6501006 40 49.3 53.8 50 60
6HK(1,2)6501306 52 62.5 68.5 70 70
6HK(1,2)6501506 60 70.9 77.7 80 80
6HK(1,2)6501806 72 84.1 92.4 90 100
6HK(1,2)6502006 80 92.5 101.7 100 110
42C
6HK(0,1)6500206 10 16.8 18.0 20 20
6HK(0,1)6500506 20 27.6 29.9 30 30
6HK(0,1)6500806 32
40.9 44.6 45 45
6HK(0,1)6501006 40 49.3 53.8 50 60
6HK(1,2)6501306 52 62.5 68.5 70 70
6HK(1,2)6501506 60 70.9 77.7 80 80
6HK(1,2)6501806 72 84.1 92.4 90 100
6HK(1,2)6502006 80 92.5 101.7 100 110
48C
6HK(0,1)6500206 10 19.3 20.5 20 25
6HK(0,1)6500506 20 30.1 32.4 35 35
6HK(0,1)6500806 32 43.4 47.1 45 50
6HK(0,1)6501006 40 51.8 56.3 60 60
6HK(1,2)6501306 52 65.0 71.0 70 80
6HK(1,2)6501506 60 73.4 80.2 80 90
6HK(1,2)6501806 72 86.6 94.9 90 100
6HK(1,2)6502006 80 95.0 104.2 100 110
For notes, see Page 14.
