TABLE 11 - SUPPLY AIR BLOWER PERFORMANCE
Blower
RPM
CFM
9600 10800 12000 13200 14400
SP BHP KW SP BHP KW SP BHP KW SP BHP KW SP BHP KW
800 0.97 4.71 4.09 0.76 5.46 4.71 0.48 6.16 5.30 ------
850 1.18 5.31 4.59 1.00 6.12 5.26 0.74 6.87 5.89 0.30 7.67 6.57 - - -
900 1.40 5.88 5.06 1.24 6.79 5.83 1.00 7.50 6.43 0.57 8.42 7.17 0.35 9.31 7.92
950 1.67 6.60 5.67 1.53 7.73 6.62 1.29 8.36 7.13 0.86 9.25 7.87 0.65 10.43 8.96
1000 1.96 7.38 6.33 1.82 8.29 7.07 1.58 9.14 7.77 1.16 10.00 8.53 0.95 11.15 9.69
1050 2.23 8.04 6.87 2.09 9.00 7.66 1.88 9.92 8.46 1.46 11.00 9.54 1.26 12.12 10.59
1100 2.50 8.63 7.35 2.38 9.65 8.22 2.17 10.80 9.34 1.78 12.05 10.53 1.58 13.20 11.71
15 HP Motor and Drive
maximum 17.25 HP
10 HP Motor and Drive
maximum 11.5 HP
MODEL DSC360
Blower
RPM
CFM
12800 14400 16000 17600 19200
SP BHP KW SP BHP KW SP BHP KW SP BHP KW SP BHP KW
900 1.12 8.84 7.55 0.75 10.11 8.76 0.30 11.59 10.03 ------
950 1.42 9.73 8.44 1.05 11.17 9.66 0.60 12.73 11.02 ------
1000 1.72 10.59 9.16 1.36 12.19 10.55 0.92 13.78 11.96 0.42 15.45 13.49 - - -
1050 2.00 11.50 9.95 1.66 13.16 11.40 1.23 14.78 12.86 0.76 16.56 14.53 0.21 18.45 16.23
1100 2.30 12.27 10.62 1.98 14.10 12.24 1.58 15.83 13.84 1.10 17.61 15.49 0.55 19.54 17.28
1150 2.62 13.16 11.38 2.33 15.00 13.06 1.93 16.93 14.87 1.47 18.74 16.50 0.92 20.60 18.38
1190 2.89 13.79 11.97 2.60 15.73 13.75 2.22 17.70 15.57 1.76 19.58 17.32 1.25 21.52 19.36
NOTE: SP - Available Static Pressure in IWG to overcome the resistance of additional unit options and accessories and anything external to the unit.
*Unit resistance is based on a “Cooling Only” unit with wet evaporator coil, 2" throwaway or cleanable filters, no and/or fixed outside air, and bottom side x side duct connections.
20 HP Motor and Drive
maximum 23 HP
15 HP Motor and Drive
maximum 17.25 HP
MODEL DSC480
530.25-N3Y
